Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics

Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics

Large Image :  Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics

Product Details:
Place of Origin: Anhui, China
Brand Name: TOPLOONG
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $3,600-3,980 / set
Contact Now
Detailed Product Description
Applicable Material: Metal, Steels Condition: New
Laser Type: Fiber Laser Cutting Speed: 12m /min
Graphic Format Supported: AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP Cutting Thickness: 0.5-3mm
Cnc Or Not: Yes Cooling Mode: Water Cooling
Laser Head Brand: Raytools Servo Motor Brand: Leadshine
Guiderail Brand: HIWIN Control System Brand: Cypcut
Weight: 350 Key Selling Points: Competitive Price
Optical Lens Brand: II-VI Warranty: 1 Year
Mode Of Operation: Continuous Wave Configuration: 3-axis
Products Handled: Sheet Metal Feature: SERVO-MOTOR
Product Name: Fiber Laser Metal Cutting Machine Keyword: Laser Metal Cutting Cnc Machine
Function: Fiber Laser Cutting Metal Laser Power: 1000W /1500W/ 2000W / 3000W
Cutting Materials: Stainless Steel Carbon Steel Aluminum After-sales Service Provided: Video Technical Support
Laser Head: Raytools Cutting Head Laser Source: MXA RECI
Color: Blue-white-Black-lemon Optional: Spliced Table

Product Overview

CNC FIBER LASER CUTTING MACHINE

Machine features: 1. High precision,Smooth and burr-free, especially suitable for Metal Designs advertising companies. 2. Integrated TOPLOONG cutting system, delivering precise and consistent cutting performance. 3. Machine adopt Detachable design structural, smaller size 1cbm only, cheaper shipping cost. https://youtube.com/shorts/EaGW6cDq7KA?feature=share
FEATURES AT A GLANCE
COMPACT DIMENSIONS
EXTENDING UNDERCARRIAGE
SAFETY FRAME
SIMPLE CONTROL
SEASY MAINTENANCE
VERSATILITY
EXTENDING UNDERCARRIAGE
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 0
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 2
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 4
Right elevation
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 6
Left elevation
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 8
Front elevation
PRODUCT SPECIFICATIONS
No
Item
Data
1
Power
1.5 2 3KW
2
Capacity
0.3-30mm
3
Operating system
RAYTOOLS PC
4
X rail effective
1500mm
5
Y rail effective
3000mm
6
Motor type
Servo motor drive
7
Laser source
MAX RECI
8
Rack gears
Helical
PRODUCT CONFIGURATION
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 10
water chiller
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 12
Racks gear
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 14
servo motor
SALES AND SERVICE NETWORK
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 16
Successful Project
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 18
Project in Thailand
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 20
Project in India
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 22
Project in Russia
SIMILAR PRODUCTS
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 24
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 26
Portable Small Metal CNC Fiber Laser Cutter Hiwin Guid Rail Supports Easy-to-Use Gantry Design Cypcut AI Dxf Cut Graphics 28
FAQ
Cut thickenss Gas options 1200W(220v single phase): 1. >13bar air compressor (cut carbon steel 0.3-4mm , stainless steel,aluminum 0.3-4mm) 2. oxygen cylinder (cut carbon steel 0.3-12mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-4mm) Average power consumption 3-4KW Peak 6KW Cut thickenss Gas options 1500W(220v single phase): 1. >13bar air compressor (cut carbon steel 0.3-6mm , stainless steel,aluminum 0.3-6mm) 2. oxygen cylinder (cut carbon steel 0.3-16mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-6mm) Average power consumption 4.5-5KW Peak 7.5KW Cut thickenss Gas options 2000W(220v single phase): 1. >13bar air compressor (cut carbon steel 0.3-10mm , stainless steel,aluminum 0.3-8mm) 2. oxygen cylinder (cut carbon steel 0.3-20mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder (cut fine quality stainless steel , aluminum 0.3-8mm) Average power consumption 6-7KW Peak 9KW Cut thickenss Gas options 3000W(380v 3phase): 1. air compressor (cut carbon steel 0.3-12mm , stainless steel,aluminum 0.3-10mm) 2. oxygen cylinder (cut fine quality carbon steel 0.3-22mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-10mm) Average power consumption 9-10KW Peak 15KW Cut thickenss Gas options 6000W(380v 3phase): 1. air compressor (cut carbon steel 0.3-18mm , stainless steel,aluminum 0.3-18mm) 2. oxygen cylinder (cut fine quality carbon steel 0.3-24mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel ,aluminum 0.3-20mm) Cut thickenss Gas options 12000W(380v 3phase): 1. air compressor (cut carbon steel 0.3-25mm , stainless steel,aluminum 0.3-30mm) 2. oxygen cylinder (cut fine quality carbon steel 0.3-40mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel ,aluminum 0.3-40mm)
